PTIMUM Time Switches & Timer Modules

Digital Fused Spur Timer One Button Boost Timer

Product Code OP-DFST Product Code OP-EBT2

The OP-DFST is a digital fused-spur time switch. The timer The OP-EBT2 is a two hour electronic, one-button boost
is suitable for patress box mounting. The 7 day programming timer with visual indicator. There are four pre-set timed
logic controls a mains-linked switch, with a resistive rating outputs. Suitable for installation on a surface or in-wall
of 13 amperes. There is an inbuilt rechargeable cell to keep pattress box. The electronic timer controls an internally
the timer running in the event of a loss of mains power. The linked output relay, with a resistive rating of 16 amps. An
output can be disconnected by an integrated double-pole earth park terminal is provided. Surface-run cord outlet with
isolator switch; the load is protected by a replaceable cable restraint. Press up to 4x to select boost output, press
BS1362 13 Ampere cartridge fuse, within a removeable again to cancel.
caddy.

• Digital fused spur timer • 2 Hour electronic Boost Timer
• 24 ON/OFF programmable periods • Socket-box mounting
• 13 Ampere switch rating • Selectable boost- 15min, 30min, 1Hr & 2Hr
• Manual override • Blue lit visual indicator
• Double-pole isolation • 230v input & output
• BS 1362 pre-fitted 13Amp fuse • Resistive load 16 amperes
• Patress box mounting • Quartz regulated accuracy (typically +/- 1.0s)
• Temperature rating: -10T45
