Specifications
28mm Motorised Mid Position Valve
Product Code OP-MID28 • 3 Port Mid-Position 28mm
• Supply voltage 220-240V AC 50Hz
• Power consumption 6W • Cable length one metre
• Operating temperature range: +5°C to +88°C
• Max. Differential pressure = 1 Bar
• Max. Static pressure 10.0 Bar
• Max. Ambient temperature 52°C
• 4rpm for greater control
• Brass geared synchronous motor
22mm 2 Port Motorised Zone Valve
Product Code OP-2PORT • 2 Port 22mm
• Supply voltage 220-240V AC 50Hz
• Power consumption 6W • Cable length one metre
• Operating temperature range: +5°C to +88°C
• Max. Differential pressure = 1 Bar
• Max. Static pressure 10.0 Bar
• Max. Ambient temperature 52°C
• 5rpm for greater control
• Brass geared synchronous motor
28mm 2 Port Motorised Zone Valve
Product Code OP-2PORT28 • 2 Port 28mm
• Supply voltage 220-240V AC 50Hz
• Power consumption 6W • Cable length one metre
• Operating temperature range: +5°C to +88°C
• Max. Differential pressure = 1 Bar
• Max. Static pressure 10.0 Bar
• Max. Ambient temperature 52°C
• 5rpm for greater control
• Brass geared synchronous motor
2 Port Zone Valve & Mid Position Actuators
Product Codes OP-2PORTH & OP-MIDH • Interchangeable with Honeywell
• Supply voltage 220-240V AC 50Hz
• Power consumption 6W • Cable length one metre
• Operating temperature range: +5°C to +88°C;
• Max. Ambient temperature 52°C
• OP-2PORTH: 5rpm motor for greater control
• OP-MIDH: 4rpm motor for greater control
• Brass geared synchronous motor
