Specifications
Combi Room Thermostat

Product Code STTRS1 • Raised dial for ease of use
• Temperature control Range: +10°C to +30°C

• Switch contacts SPDT, Volt free
• Switch rating: 10A (3A) at 230V AC
• Switch differential: 0.5°C
• Ambient temperature 40°C maximum
• Class II insulation • 2 wire connection
• Suitable for heating or cooling system
• Suitable for combination boilers • ErP Class 1

Frost Thermostat
Product Code STTRFSN • Raised dial for ease of use

• Temperature control Range: -5°C to +15°C
• Switch contacts SPDT, Volt Free
• Switch rating: 10A (3A) at 230V AC
• Switch differential: 0.5°C

• Ambient temperature 40°C maximum
• Class II insulation • 2 wire connection
• Suitable for heating or cooling systems • ErP Class 1

Tamper-proof Thermostat

Product Code STTPRS • 10 (3) A @ 230 VAC µ

• Volt-free contact
• For mains or low voltage applications
• Range: 10°C to 30°C
• For wall mounting
• In-wall or surface-run wiring
• Tamper proof cover

Pipe & Cylinder Thermostat
Product Code PCS • Designed to mount on water pipes and hot

water cylinders
• Range: +10°C to +90°C

• Rating: 16 (4) Amps at 250V AC
• Switch type: Single pole / double throw
• Differential: 5°C
• IP40 protected
